Pressure Advance Camera Calibration for Klipper

This project introduces a tool to automatically calibrate the pressure advance setting for FDM 3D printers running the Klipper firmware using a low cost USB (endoscope) camera 📸 and computer vision. Pressure advance is a key feature in Klipper that enhances print quality by fine-tuning extruder behavior during acceleration and deceleration. By leveraging a camera to analyze a test pattern before each print, this tool simplifies and automates the calibration process, saving time and effort for users.

Please watch this Video where I explain the project:

⚠️ Disclaimer

🚧 Early development version - verify results manually. Not responsible for damage. Test in safe environment first.

✨ Features

• Automated Calibration: Prints and captures a test pattern with a camera and determines the optimal pressure advance value.
• Affordable Hardware: Uses a low-cost USB endoscope camera (around €6) for image capture.
• Open Source: Licensed under GPL3 which allows even commercial use, welcoming community contributions and modifications.

🤖 How It Works

1. Test Pattern Creation:
   • At the start of a print, the printer draws a series of lines with varying pressure advance values.
2. Image Capture:
   • The camera moves to the center of the test pattern takes a picture of it.
3. Image Analysis:
   • The image is processed using the open BirefNet model via the fal.ai API, which removes the background (build-plate) - I hope to get rid of this step in the future and run a small local model instead but until now this is required.
   • We identify the rectangle drawn in the pattern and crop it and fix the horrible lens distortion the cheap camera introduces.
   • Afterwards we identify the smoothest and most continuous line using OpenCV Computer Vision algorithms.
4. Calibration Application:
   • The software sets the optimal pressure advance value, and the printer continues the print with this setting.

Requirements

• Camera:
  • A cheap USB endoscope camera (approximately €5). Ensure it is full HD and has a flexible cable (they also sell a semi-solid one which likely cause problems). Theoretical a webcam could also work if it can focus on something about 10cm away. Here is the one I bought.
• Mounting:
  • The camera must be securely mounted on the printhead, facing straight down. Here you can find the mount I use which reuses the existing BLTouch mount
• free USB Port
• Klipper and ssh access

🚀 Setup

Hardware Setup

1. Mount the Camera:
   • Attach a USB endoscope camera to the printhead, facing straight down at the build plate.
   • A sample mount for the Ender 3 using the BLTouch mount is provided here.
2. Camera Orientation:
   • Plug the camera into a phone first to verify orientation or if setup in crowsnest: check in the browser. Rotate it 90° to the left so that the test pattern lines run from top to bottom in the captured image, maximizing the camera’s resolution.
3. Lighting:
   • Ensure adequate lighting with no significant glare or reflections on the build plate where the test pattern will be printed.
4. Connect the Camera:
   • Plug the camera into the printer’s USB port.

Software Setup

To set up the software, follow these steps on the printer:

1. Clone the Repository:

   git clone https://github.com/undingen/PressureAdvanceCamera.git

2. Navigate to the Project Directory:

   cd PressureAdvanceCamera

3. Add Your FAL API Key: Create a file named fal.key and insert your API key from fal.ai (used to remove the background of the captured image): Make sure to never share this API key with anyone!

   echo "<FAL_KEY>" > fal.key

4. Link to Klipper Extras: Create a symbolic link to the Klipper extras directory to add the extension:

   ln -s `pwd`/pressure_advance_camera.py ../klipper/klippy/extras/

5. Install Dependencies: Install the fal-client package using pip and OpenCV (distro package):

   pip3 install fal-client
   sudo apt install python3-opencv -y

Software Configuration

1. Crowsnest Check (if camera is configured in Crownsnest else skip this step):
   • Ensure the camera uses the best resolution available in your crowsnest.conf configuration.

     resolution: 1920x1080


2. Update printer.cfg:
   • Add the following section to your Klipper printer.cfg file and cheange the values:

     [pressure_advance_camera]
     camera_offset_x: -23    # X offset from nozzle to camera, negative is left of nozzle
     camera_offset_y: -20    # Y offset from nozzle to camera, negative is in front of nozzle
     photo_height: 50        # Height in mm to position the nozzle for photo. For my cam 5-6cm

   • If multiple cameras are connected, set the camera_id parameter to the appropriate OpenCV camera ID.
3. Check that the extension:
   • Check that klipper uses the extensions by executing HELP inside the console and looking for GCodes called DRAW_PRESSURE_ADVANCE_PATTERN or SET_PRESSURE_ADVANCE_CAMERA. If this does not show up make sure you created the symlink and the printer.cfg entry and restart Klipper.

Default Configuration

The following parameters are pre-configured and only need adjustment if your setup differs from the default (and some like the temperture is best to overwrite directly in the GCode by passing it as argument):

[pressure_advance_camera]
camera_offset_x:        # X offset from nozzle to camera, negative is left of nozzle
camera_offset_y:        # Y offset from nozzle to camera, negative is infront of nozzle
photo_height:           # Height in mm to position the nozzle for photo - for my cam 5-6cm

script_path: ~/PressureAdvanceCamera/pa_calibrate.py
#camera_id: 0            # OpenCV Camera ID or crowsnest url
camera_id: "http://localhost/webcam/?action=snapshot"
x_start: 2              # where to start the pattern
y_start: 2              # where to start the pattern
pa_start: 0.0
pa_end: 0.1
pa_step: 0.005
hotend_temp: 200        # Hotend temperature
bed_temp: 60            # Bed temperature
line_spacing: 3
width: 40
timeout: 600
speed: 100              # Speed for the fast segments
bed_mash:               # Name of the bed mesh to load, e.g. "default"

Slicer Settings

For now only tested with OrcaSlicer (but this could ofcourse also be directly done inside the Klipper macros):

• Create a copy of your printers profile but under Machine start G-Code prepend this:

DRAW_PRESSURE_ADVANCE_PATTERN HOTEND_TEMP=[nozzle_temperature] BED_TEMP=[bed_temperature]
SET_PRESSURE_ADVANCE_CAMERA

• Make a copy of you filament profile but uncheck "Enable pressure advance" (else the emitted GCode would overwrite auto configed value).

Software Dependencies

• fal.ai API Key:
  • Required for image segmentation due to the challenges of detecting lines with poor lighting and low-quality cameras. The project uses a open BirefNet model hosted on fal.ai’s servers.
  • Costs are minimal (less than $0.01 per frame/print), and new users may receive $1 credit upon signing up at fal.ai. (Note: I have no affiliation with fal.ai and hope I can change the project in the future todo all computation localy.)
• Python Packages:
  • Install fal-client as outlined in the installation steps (OpenCV, numpy and Matplotlib should already be installed).

🐉 Limitation

If the contrast between the build-plate and filament is poor — meaning if you as a human cannot reliably detect the best line from the camera image — the software will also fail. It's important to have enough light for the camera to take a good picture while also avoiding glare spots that obstruct the view.

Support me

If you find this project useful please support me so that I can spend more time on this project:

🌐 Data Collection for future local model

• All captured images are saved in a subdirectory called images.
• Users are encouraged to email me the images [email protected] or upload the images to this Issue (after ensuring no private information is included!). This data will help train a smaller, future model that can run directly on the printer. But for this to succeed a lot of different training examples are required...

📜 License

This project is licensed under the GNU General Public License v3.0 (GPL3). This means it is free to use, modify, and distribute, but any modifications must also be shared under the same open-source license.

🤝 Contributions

This is an early-stage project, and contributions are warmly welcomed! Whether it’s code improvements, bug fixes, documentation updates, or simply feedback, your input is invaluable. Please feel free to open issues or submit pull requests on GitHub.
