Web-based Editor for texts using the Applied Text as Graph concept

Demo

The static page demonstrates the editor core functionalities: https://thm-graphs.github.io/atag-editor/

This version does not always reflect the latest changes of the development process. To get a full version of the app running, follow the instructions of the next chapter.

Installation

1. If you are using Windows, make sure Windows Subsystem for Linux (WSL), Docker Desktop and Node.js (in WSL) are installed.

2. Open a command line tool (e.g. Ubuntu), select a directory, clone the repo and move into it.

   cd <your-directory-name>
   git clone https://github.com/THM-Graphs/atag-editor.git
   cd atag-editor

3. Copy the .env.example file to create your .env file.

   cp .env.example .env

   Afterwards, replace the placeholder values with actual values.

4. Install dependencies in your hosts's server and client folder.

   (cd server && npm install)
   (cd client && npm install)

5. Build docker containers and run the app

   docker compose up -d


   Please be patient, Neo4j takes its time. Wait approx. 1 minute.

You can now access the editor and the database:

• Editor start page with text overview: http://localhost:5173
• Neo4j database: http://localhost:7474

Deployment

To be updated

Customization after Deployment

If you have a deployed version of the editor, you can customize it by providing you own configuration JSON file and your own CSS stylesheet. Both files must be available via URL and are referenced with environment variables in your .env file (GUIDELINES_URL and STYLESHEET_URL).

1. Guidelines

The JSON file provided by GUIDELINES_URL is a representation of your project-specific data model. It defines which labels and properties can be used inside the neo4j database, available annotation types etc. To start, you can follow one of the guidelines files in this repository like guidelines.development.json.

Otherwise, follow this preliminary explanation for the guidelines structure:

The guidelines.json file defines the annotation schema for your text analysis project. It consists of three main sections that can be customized:

Configuration Structure

Section	Purpose	Customizable Elements
texts	Text structure/behaviour	Additional labels for Text nodes
collections	Collection structure/behaviour	Data for Collections (labels for Collection nodes, properties, possible annotations etc.)
annotations	Annotation structure/behaviour	Annotation types, categories, and categories/labels for linked Entity nodes

Collection Types

Collections define document categories with specific properties:

{
  "additionalLabel": "Letter",
  "level": "primary",
  "properties": [
    {
      "name": "status",
      "type": "string",
      "required": false,
      "editable": true,
      "visible": true
    }
  ]
}

Property	Options	Description
additionalLabel	Custom string	Additional node label
level	"primary", "secondary"	Hierarchy level
properties	Array of property objects	Custom metadata fields

Important: At least one Collection type must be set to primary. Collections with this additional node labels will be shown in the overview of the editor. All other Collection types MUST have "secondary"

Annotation Types

Annotations define how text can be marked up.

Adding Custom Annotation Types

{
  "type": "customType",
  "category": "project", // Groups annotation type in a category on the page. Is not stored in the database anywhere
  "defaultSelected": true, // if annotation type is enabled per defauled in the filter panel
  "isZeroPoint": false, // usually "false". This means, an annotation can have exactly two annotated characters and covers a phenomen between these two (e.g. deleted text)
  "hasAdditionalTexts": true, //deprecated, set always to true for now, but it will be available for each annotation type anyway
  "properties": [
    {
      "name": "subType",
      "type": "string",
      "options": ["option1", "option2"],
      "required": true,
      "editable": true,
      "visible": true
    }
  ]
}

Entity Categories

"entities": [
  {"category": "places", // Category, is used to group linked entities in the annotation form
   "nodeLabel": "Place" // additional node label of the entity. Mainly used to fetch autocomplete data when typing in the input field
   },
]

Property Configuration

Each property supports these options:

Option	Type	Description
name	string	Property identifier
type	array, boolean, date, date-time, integer, number, string, time	Data type. Different types get different input fields (dropdown calendars, number modifiers etc.)
required	boolean	Whether field is mandatory
editable	boolean	Can users modify this field
visible	boolean	Is ivsible in interface. For example, the annotation type should NOT be editable - when an annotation is created, it is fix forever.
options	array	Predefined values for dropdowns

2. Styles

With the CSS stylesheet provided by STYLESHEET_URL you can style the appearance of the annotations inside the text as well as icons for each annotation type. You can refer to the annotations.css stylesheet in this repository to see how the styling is done. The class name of the span element must match the annotation type exactly.

#text > span:has(span.myCustomAnnotationType) {
  background-color: lightgreen;
  opacity: 0.7;
}

Icons for annotation types are displayed in every place an annotation is referenced (toolbar, overview, details panel):

The icons can be embedded via background or background-image CSS property. It uses the native url CSS function to apply the icon. The icon container is an HTML element with the base class annotation-type-icon-, so to apply your own style rules, add the annotation type to the class (like annotation-type-icon-myCustomAnnotationType)

You have two possiblitities here:

1. Provide icons somewhere else and reference them via URL. This is is useful if you have e.g. a GitHub Repository or Cloud where you host your own SVGs.

.annotation-type-icon-myCustomAnnotationType {
  background-image: url('https://raw.githubusercontent.com/THM-Graphs/atag-editor/refs/heads/main/client/public/icons/entity.svg');
}

2. Use a data URL where you can write the SVG directly into the url function.

.annotation-type-icon-myCustomAnnotationType {
}

Please note that you don't HAVE to add an icon for each annotation type. It is only a matter of styling, and the buttons will have the annotation type string as default:
